Horizontal Press

Product Description

When it becomes cumbersome and difficult to load a part into a convention, vertically-acting press, especially with parts which either too long or too short to load in the vertical assembly press, the side-acting horizontal press is a best solution for this case. Lexson’s hydraulic horizontal press can be designed in the proper frame structure such as 4-post or 2-post according to the specific applications. The horizontal presses have a fixed bed and a movable plate, and a fully adjustable ram stroke. Guided by quality graphite-impregnated self-lubricated bronze bushings and solid, chrome-plated posts, each horizontal press is ensured years of maintenance-free and reliable operation.

ADVANTAGES

Advantages of Lexson side-acting hydraulic horizontal presses

• Side-acting design for convenience loading and unloading parts
• Modular design, customize to your specifications
• Superior rigidity and bed to platen parallelism
• Precision guided moving slide (platen)
• Fast, easy and safe setup and operation
• Years of maintenance-free and reliable operation.

Lexson offers several standard horizontal press. These standardized horizontal hydraulic press can also be modified with specific tonnage, stroke, shut height, bed size to meet your special need.

MACHINE PARAMETERS

Detailed technical specification of Lexson-P08 series hydraulic horizontal press:

Please note that we can custom-build horizontal presses directly to your specifications.

Description

Lexson-P08 75T Lexson-P08 100T Lexson-P08 150T Lexson-P08 250T Lexson-P08 300T
Nominal Force 750 KN 1000 KN 1500 KN 2500 KN

3000 KN

Structure

4 post horizontal press 4 post horizontal press 4 post horizontal press 4 post horizontal press 4 post horizontal press
Cylinder Stroke 300 mm 300 mm 400 mm 500 mm

650 mm

Max. Open Height

900 mm 1100 mm 1500 mm 2000 mm 2600 mm
Bed Table 800*600 mm 1000*800 mm 1200*1000 mm 1200*1200 mm

1500*1200 mm

Closing Speed

140 mm/s 140 mm/s 120 mm/s 100 mm/s 120 mm/s
Pressing Speed 25 mm/s 25 mm/s 20 mm/s 18 mm/s

18 mm/s

Return Speed

110 mm/s 110 mm/s 100 mm/s 80 mm/s 80 mm/s
Motor 4 Pole, 7.5 KW 4 Pole, 11.5 KW 4 Pole, 13.5 KW 4 Pole, 17.5 KW

4 Pole, 22 KW

Power Supply

3Phase, 220/380/415/480VAC, 50/60HZ 3Phase, 220/380/415/480VAC, 50/60HZ 3Phase, 220/380/415/480VAC, 50/60HZ 3Phase, 220/380/415/480VAC, 50/60HZ 3Phase, 220/380/415/480VAC, 50/60HZ
System Pressure 20 Mpa 20 Mpa 20 Mpa 21 Mpa

24 Mpa

Approx. Weight

4.5 ton 7 Ton 9 Ton 12.5 Ton

14 Ton

OPTIONS

•  Interlocked, hinged metal mesh guards on sides
•  Safety sensors
•  T-Slots and mounting holes on moving platen and bed
•  Pedal switch
•  Automatic pneumatic safety door
•  Color HMI
•  Linear position sensor
•  Load cell
